Milling	Home >

TANK POWER, 4 FLUTE DOUBLE END (E9986)

View Speeds and Feeds Data

TANK POWER, 4 FLUTE DOUBLE END (E9986)

MILL	SHANK	LENGTH	OVERALL	Uncoated	TiAlN Coated
DIAMETER	SHANK DIAMETER	OF CUT	LENGTH	EDP No.	EDP No.
1/8	3/8	3/8	3-1/16	E9986008	E9986008TF
3/16	3/8	1/2	3-1/4	E9986012	E9986012TF
1/4	3/8	5/8	3-3/8	E9986016	E9986016TF
5/16	3/8	3/4	3-1/2	E9986020	E9986020TF
3/8	3/8	3/4	3-1/2	E9986024	E9986024TF
1/2	1/2	1	4-1/8	E9986032	E9986032TF
5/8	5/8	1-3/8	5	E9986040	E9986040TF
3/4	3/4	1-5/8	5-5/8	E9986048	E9986048TF
7/8	7/8	1-7/8	6-1/8	E9986056	E9986056TF
1	1	1-7/8	6-3/8	E9986064	E9986064TF
