Milling
HIGH PERFORMANCE CARBIDE STEEL
4G MILL CARBIDE, 2 FLUTE CORNER RADIUS (GMF18)

  4G MILL CARBIDE, 2 FLUTE CORNER RADIUS
EDP No. Corner Radius Mill Diameter Shank Diameter Length of Cut Overall Length
GMF18003R.0083/641/43/322
GMF18901R.0123/641/43/322
GMF18004R.0081/161/45/322
GMF18902R.0121/161/45/322
GMF18903R.0201/161/45/322
GMF18005R.0085/641/41/42
GMF18904R.0125/641/41/42
GMF18905R.0205/641/41/42
GMF18008R.0081/81/45/162-3/8
GMF18906R.0121/81/45/162-3/8
GMF18907R.0201/81/45/162-3/8
GMF18009R.0089/641/43/82-3/4
GMF18908R.0129/641/43/82-3/4
GMF18909R.0209/641/43/82-3/4
GMF18910R.0409/641/43/82-3/4
GMF18013R.00813/641/41/23-1/2
GMF18911R.01213/641/41/23-1/2
GMF18912R.02013/641/41/23-1/2
GMF18913R.04013/641/41/23-1/2
GMF18016R.0081/41/45/82-3/8
GMF18914R.0121/41/45/82-3/8
GMF18915R.0201/41/45/82-3/8
GMF18916R.0401/41/45/82-3/8
GMF18917R.0081/41/45/83-1/2
GMF18918R.0121/41/45/83-1/2
GMF18919R.0201/41/45/83-1/2
GMF18920R.0401/41/45/83-1/2
GMF18020R.0205/165/163/42-3/4
GMF18921R.0405/165/163/42-3/4
GMF18922R.0205/165/163/44
GMF18923R.0405/165/163/44
GMF18924R.0605/165/163/44
GMF18925R.0805/165/163/44
GMF18024R.0203/83/813
GMF18926R.0403/83/813
GMF18927R.0203/83/814
GMF18928R.0403/83/814
GMF18929R.0603/83/814
GMF18930R.0803/83/814
GMF18032R.0201/21/21-3/163-1/8
GMF18931R.0401/21/21-3/163-1/8
GMF18932R.0201/21/21-3/164-1/4
GMF18933R.0401/21/21-3/164-1/4
GMF18934R.0601/21/21-3/164-1/4
GMF18935R.0801/21/21-3/164-1/4
GMF18936R.1001/21/21-3/164-1/4
GMF18937R.1181/21/21-3/164-1/4
GMF18036R.0409/165/81-3/86
GMF18040R.0405/85/81-1/46
GMF18938R.0805/85/81-1/46
GMF18048R.0403/43/41-1/26
GMF18939R.0803/43/41-1/26
