Milling
HIGH PERFORMANCE POWDERED METAL STAINLESS STEEL TITANIUM
TANK POWER, ASP60 2 FLUTE DOUBLE END MILLS

 ASP60 2 FLUTE DOUBLE END MILLS
MILL DIAMETER SHANK DIAMETER LENGTH OF CUT OVERALL LENGTH EDP No. EDP No.
1/8 3/8 3/8 3-1/16 E9984008 E9984008TF
3/16 3/8 7/16 3-1/8 E9984012 E9984012TF
1/4 3/8 1/2 3-1/8 E9984016 E9984016TF
5/16 3/8 9/16 3-1/8 E9984020 E9984020TF
3/8 3/8 9/16 3-1/8 E9984024 E9984024TF
1/2 1/2 13/16 3-3/4 E9984032 E9984032TF
5/8 5/8 1-1/8 4-1/2 E9984040 E9984040TF
3/4 3/4 1-5/16 5 E9984048 E9984048TF
7/8 7/8 1-9/16 5-1/2 E9984056 E9984056TF
1 1 1-5/8 5-7/8 E9984064 E9984064TF
