Milling
HIGH PERFORMANCE CARBIDEL GRAPHITE
2 FLUTE LONG REACH BALL NOSE

  2 FLUTE LONG REACH BALL NOSE
Radius of Mill Shank Length Length Overall Neck EDP NO
Ball Nose Diameter Diameter of Cut Below Shank Length Diameter
R.03915/641/83/83/440.07699678
R1/161/81/85/8140.12099679
R3/323/163/161-1/824-3/40.18299980
R3/323/161/41-1/824-3/40.18699680
R1/81/41/41-1/8260.23099681
R5/325/165/161-1/22-3/860.29399682
