Milling Home > Milling > HIGH PERFORMANCE > CARBIDE > STEEL
4G MILL CARBIDE, 2 FLUTE (3/16 SHANK) (GMF23)
View Speeds and Feeds Data
EDP No. Mill
Diameter		 Shank
Diameter		 Length
of Cut		 Overall
Length
GMF23913 .040 3/16 3/32 2
GMF23914 .047 3/16 1/8 2
GMF23915 .050 3/16 1/8 2
GMF23916 .055 3/16 5/32 2
GMF23917 .060 3/16 5/32 2
GMF23918 .063 3/16 5/32 2
GMF23919 .070 3/16 3/16 2
GMF23920 .079 3/16 1/4 2
GMF23921 .087 3/16 1/4 2
GMF23922 .094 3/16 1/4 2
GMF23923 .098 3/16 5/16 2
GMF23924 .102 3/16 5/16 2
GMF23925 .106 3/16 5/16 2
GMF23926 .110 3/16 5/16 2
GMF23927 .120 3/16 5/16 2
