Milling Home > Milling > HIGH PERFORMANCE > CARBIDE > STEEL
4G MILL CARBIDE, 4 FLUTE (GMF25 SERIES)
View Speeds and Feeds Data
EDP No. Mill
Diameter		 Shank
Diameter		 Length
of Cut		 Overall
Length
GMF25003 3/64 1/4 3/32 2
GMF25004 1/16 1/4 5/32 2
GMF25005 5/64 1/4 1/4 2
GMF25006 3/32 1/4 1/4 2
GMF25008 1/8 1/4 5/16 2
GMF25009 9/64 1/4 3/8 2
GMF25012 3/16 1/4 3/8 2
GMF25013 13/64 1/4 5/8 2-3/8
GMF25014 7/32 1/4 5/8 2-3/8
GMF25016 1/4 1/4 5/8 2-3/8
GMF25017 17/64 5/16 11/16 2-3/8
GMF25018 9/32 5/16 3/4 2-3/8
GMF25019 19/64 5/16 3/4 2-3/8
GMF25020 5/16 5/16 3/4 2-3/4
GMF25022 11/32 3/8 7/8 2-3/4
GMF25023 23/64 3/8 7/8 2-3/4
GMF25024 3/8 3/8 1 3
GMF25028 7/16 1/2 1-3/16 3
GMF25032 1/2 1/2 1-3/16 3-1/8
GMF25036 9/16 9/16 1-3/8 4
GMF25901 9/16 5/8 1-3/8 4
GMF25040 5/8 5/8 1-1/2 4
GMF25044 11/16 5/8 1-3/4 4
GMF25048 3/4 3/4 1-3/4 4
