Milling Home > Milling > HIGH PERFORMANCE > CARBIDE > STEEL
4G MILL CARBIDE, 4 FLUTE (GMF26 SERIES)
View Speeds and Feeds Data
EDP No. Mill
Diameter		 Shank
Diameter		 Length
of Cut		 Overall
Length
GMF26003 3/64 1/4 3/32 2
GMF26004 1/16 1/4 5/32 2
GMF26005 5/64 1/4 1/4 2
GMF26006 3/32 1/4 1/4 2
GMF26008 1/8 1/4 5/16 2
GMF26012 3/16 1/4 3/8 2
GMF26013 13/64 1/4 5/8 2-3/8
GMF26016 1/4 1/4 5/8 2-3/8
GMF26020 5/16 5/16 3/4 2-3/4
GMF26024 3/8 3/8 1 3
GMF26032 1/2 1/2 1-3/16 3-1/8
GMF26040 5/8 5/8 1-1/4 4
GMF26048 3/4 3/4 1-3/4 4
