YG-1: BEST VALUE IN THE WORLD OF CUTTING TOOLS

Size	T.P.I	EDP No.				Limit	Overall Length	Thread Length	Neck Length	Shank Diameter	Square Size	Square Length	No. of Flute
D1	T.P.I	Steam Oxide	Bright	TiN	Hardslick	Limit	L2	L1	L3	D2	K	KI	No. of Flute
#4	40UNC	C2162	C3162	C4162	D9162	H2	1.874	0.563	0.799	0.141	0.110	0.190	2
#5	40UNC	C2202	C3202	C4202	D9202	H2	1.937	0.626	0.882	0.141	0.110	0.190	3
#6	32UNC	C2243	C3243	C4243	D9243	H3	2.000	0.689	0.965	0.141	0.110	0.190	3
#8	32UNC	C2283	C3283	C4283	D9283	H3	2.126	0.752	1.047	0.168	0.131	0.250	3
#10	24UNC	C2323	C3323	C4323	D9323	H3	2.374	0.906	1.220	0.194	0.152	0.250	3
#10	32UNF	C2343	C3343	C4343	D9343	H3	2.374	0.906	1.220	0.194	0.152	0.250	3
1/4	20UNC	C2403	C3403	C4403	D9403	H3	2.500	1.000	1.354	0.255	0.191	0.310	3
1/4	20UNC	C2405	C3405	C4405	D9405	H5	2.500	1.000	1.354	0.255	0.191	0.310	3
1/4	28UNF	C2423	C3423	C4423	D9423	H3	2.500	1.000	1.354	0.255	0.191	0.310	3
5/16	18UNC	C2443	C3443	C4443	D9443	H3	2.720	1.126	1.500	0.318	0.238	0.380	3
5/16	18UNC	C2445	C3445	C4445	D9445	H5	2.720	1.126	1.500	0.318	0.238	0.380	3
5/16	24UNF	C2463	C3463	C4463	D9463	H3	2.720	1.126	1.500	0.318	0.238	0.380	3
3/8	16UNC	C2483	C3483	C4483	D9483	H3	2.937	1.252	1.646	0.381	0.286	0.440	3
3/8	16UNC	C2485	C3485	C4485	D9485	H5	2.937	1.252	1.646	0.381	0.286	0.440	3
3/8	24UNF	C2503	C3503	C4503	D9503	H3	2.937	1.252	1.646	0.381	0.286	0.440	3
7/16	14UNC	C2523	C3523	C4523	D9523	H3	3.157	1.437	-	0.323	0.242	0.410	3
7/16	14UNC	C2525	C3525	C4525	D9525	H5	3.157	1.437	-	0.323	0.242	0.410	3
7/16	20UNF	C2543	C3543	C4543	D9543	H3	3.157	1.437	-	0.323	0.242	0.410	3
7/16	20UNF	C2545	C3545	C4545	D9545	H5	3.157	1.437	-	0.323	0.242	0.410	3
1/2	13UNC	C2563	C3563	C4563	D9563	H3	3.374	1.657	-	0.367	0.275	0.440	3
1/2	13UNC	C2565	C3565	C4565	D9565	H5	3.374	1.657	-	0.367	0.275	0.440	3
1/2	20UNF	C2583	C3583	C4583	D9583	H3	3.374	1.657	-	0.367	0.275	0.440	3
1/2	20UNF	C2585	C3585	C4585	D9585	H5	3.374	1.657	-	0.367	0.275	0.440	3
9/16	12UNC	C2605	C3605	C4605	D9605	H5	3.594	1.657	-	0.429	0.322	0.500	3
9/16	18UNF	C2625	C3625	C4625	D9625	H5	3.594	1.657	-	0.429	0.322	0.500	3
5/8	11UNC	C2643	C3643	C4643	D9643	H3	3.811	1.811	-	0.480	0.360	0.560	4
5/8	11UNC	C2645	C3645	C4645	D9645	H5	3.811	1.811	-	0.480	0.360	0.560	4
5/8	18UNF	C2663	C3663	C4663	D9663	H3	3.811	1.811	-	0.480	0.360	0.560	4
3/4	10UNC	C2703	C3703	C4703	D9703	H3	4.252	2.000	-	0.590	0.442	0.690	4
3/4	10UNC	C2705	C3705	C4705	D9705	H5	4.252	2.000	-	0.590	0.442	0.690	4
3/4	16UNF	C2723	C3723	C4723	D9723	H3	4.252	2.000	-	0.590	0.442	0.690	4
7/8	9UNC	C2744	C3744	C4744	D9744	H4	4.689	2.220	-	0.697	0.523	0.750	4
7/8	14UNF	C2766	C3766	C4766	D9766	H6	4.689	2.220	-	0.697	0.523	0.750	4
1	8UNC	C2784	C3784	C4784	D9784	H4	5.126	2.500	-	0.800	0.600	0.810	4
